Single-shot 3D imaging with point cloud projection based on metadevice

Three-dimensional (3D) imaging is a crucial information acquisition technology for light detection, autonomous vehicles, gesture recognition, machine vision, and other applications. Metasurface, as a subwavelength scale two-dimensional array, offers flexible control of optical wavefront owing to abundant design freedom. Metasurfaces are promising for use as optical devices because they have large field of view and powerful functionality. In this study, we propose a flat optical device based on a single-layer metasurface to project a coded point cloud in the Fourier space and explore a sophisticated matching algorithm to achieve 3D reconstruction, offering a complete technical roadmap for single-shot detection. We experimentally demonstrate that the depth accuracy of our system is smaller than 0.24 mm at a measurement distance of 300 mm, indicating the feasibility of the submillimetre measurement platform. Our method can pave the way for practical applications such as surface shape detection, gesture recognition, and personal authentication.

Xiaoli Jing, Ruizhe Zhao, Xin Li, Qiang Jiang, Chengzhi Li, Guangzhou Geng, Junjie Li, Yongtian Wang, Lingling Huang
